pewag LEVO Hook LH

The pewag levo hook LH stands for a new generation of lifting devices. Thanks to its powerful features, the process of attaching and releasing loads is automated. It is supporting operators in difficult working conditions, for instance when working at height or in hazardous conditions. In a professional context, operator safety should be the top priority at all times. The pewag levo hook LH makes this a reality: Operated by radio control, the rotatable lifting hook gets perfect grip straightaway and releases the load without manual assistance.

Available in the LH5 (5T), LH8 (8T), LH16 (16T) & LH32 (32T) ranges.

The pewag levo hook LH5 provides advanced functionality, enhancing the flexibility of any lifting operation. The LH5 can be fitted with a magnet. With the powerful combination of motor and battery, the hook can operate for up to 70 hours.
levo safety feature – Prevents unintentional opening under a load of 20 kg or more.

The pewag levo hook LH8 provides advanced functionality, enhancing the flexibility of any lifting operation. The LH8 can be fitted with a magnet. With the powerful combination of motor and battery, the hook can operate for up to 70 hours.
levo safety feature – Prevents unintentional opening under a load of 20 kg or more.

The pewag levo hook LH16 is equipped with a magnet capable of lifting ferromagnetic materials weighing up to 12.5 kg. The placement of the magnet allows for effortless central positioning of the load.
levo safety feature – Prevents unintentional opening under a load of 40 kg or more.

The pewag levo hook LH32 comes with an additional brake that prevents the hook from automatically lowering when the hook is open. The optional magnet enables lifting of ferromagnetic materials weighing up to 12.5 kg. Furthermore, the placement of the magnet allows for effortless central positioning of the load.
levo safety feature – Prevents unintentional opening under a load of 80 kg or more.

LEVO - Smart facts for smart lifting.
• Automated loading and unloading from a safe distance (100 m).
• Use of a high-quality rechargeable lithium-ion battery (84.42 Wh) with additional over- and undercharging protection.
• The dual safety mechanism makes levo products the safest remote-controlled slings in the world.
• Optimised transmission system
• Protection class IP65
• Additional coatings (PCP, GZN, FLZN) to increase service life under extreme environmental conditions.
• Operating temperature -20°C to +60°C (extension possible)

100 % safe (ISO 13849)
Accidental opening of the levo hook under load is impossible secured communication between hook and remote control, safety factor against break: 4:1

Excellent pewag quality
Patented tool-free locking of the rotation lock, tool-free initial mounting, TÜV-certified, pewag know-how

Complete range of services (on-the-job training)
E-learning, on- site trainings, pewag expert support during initial operation, repair
